RTX: COLLINS AEROSPACE’S FIRST-OF-ITS-KIND FACILITY PREPARES TO TEST NEW TECHNOLOGIES
The Grid, Collins Aerospace’s new facility, has the power to make electrified flight a reality.
This setup will help The Grid test power quality for unmanned aerial vehicles and prepare the lab for larger systems in the future.
On a table at a bright, new lab in Rockford, Illinois, a stream of electrons begins its journey.
That journey starts with a device called a dynamometer, which spins a generator. In milliseconds, the electrons travel through a neatly tied bundle of cables. From there, they flow into a rectifier, a black box that will change the way they move — from back-and-forth (alternating current) to one direction (direct current).
This simple but important test will show whether the rectifier – small enough to fit in a backpack – can function at the voltage necessary for a hybrid electric unmanned aerial vehicle. That, in turn, will provide foundational knowledge for a larger effort to bring hybrid electric propulsion to single-aisle aircraft.
The test is one of many taking place at The Grid, an advanced electric power systems lab run by Collins Aerospace, an RTX business. The lab will allow Collins to develop electric motors, controllers, generators and distribution systems to achieve electrified propulsion on aircraft of all sizes. The effort to electrify propulsion is part of an industrywide goal to reduce carbon emissions.
What The Grid can do
The Grid’s 25,000-square-foot layout gives it two advantages: the ability to test full systems rather than individual parts, and the flexibility to do it in their real-world configuration.
At each corner of the lab, there’s equipment for a setup like the one they are currently using to test UAV systems and mature The Grid. The lab can have up to eight dynamometers with each serving as a starting block for a project. The dynamometers act as an engine as they spin, and, from there, researchers can add on a piece at a time to create subsystems that they can validate as they build.
The Grid’s lab floor is as long as a football field is wide, which gives researchers room to test full systems in their real-world configuration.
The lab can also combine multiple setups to mimic multiple engines on an aircraft and pair them with software to simulate a flight from takeoff to landing.
Powering The Grid
The Grid has 8 megawatts of electricity and the capacity for up to 15. That’s plenty of power, but it’s also supplied in a new way. The lab has its own substation from the local utility, which helps ensure a reliable source of power at adequate voltage.
Collins is building its first solar array there, too, which will provide clean electricity for The Grid and other labs and offices at the Rockford location. The Grid's load bank, a component used to absorb power during tests, was also designed with sustainability in mind. Rather than wasting excess electricity as heat, the bank can send it to the utility’s main grid to be used by homes and businesses nearby.
Additionally, the lab can emulate up to 4 megawatts of battery storage to test how battery systems will work on aircraft.
What’s next for The Grid
In a control room next to the lab, a team is working on an important piece of that puzzle: software.
The Grid can collect up to 2 million data points per second during a test, and as the rectifier’s power quality test runs next door, that data shows on control room screens as wavy lines whose peaks and valleys give the team valuable information.
The software they’re refining allows them to record test data and remotely operate equipment in the lab with just a few clicks. That seems simple, principal engineer Scott Barker said, but one click handles several layers of logic and getting it right requires hundreds of small tests. They’re designing the software to be as modular as the lab itself so that, when complete, its logic can be reused for other projects to reduce the time it takes to set up.
The team is preparing for several new projects including SWITCH, a program for the European Union’s Clean Aviation Joint Undertaking where Collins, Pratt & Whitney and other partners are developing hybrid electric and water-injected turbofan technology to reduce fuel burn and carbon emissions.
Pratt & Whitney will provide a hybrid-electric-ready GTF engine while Collins will provide megawatt-class electric machines and power electronics, high-voltage DC distribution and protection, thermal management components and nacelle architectures for the system.
The Grid will help test how the pieces will work together. Instead of the six to nine months required to set up a new project in The Grid today, the modular components they’re building will help reduce that to roughly two months.
